CÂBLE RIGIDE ARMÉ CUIVRE U-1000 RVFV

NM 06.3.006 / XP C 32-321

Utilisation

  • Installations et connexions des basses tensions industrielles
  • Alimentation de puissance ou de liaisons de postes fixes
  • Pose en chemins de câble sur tablettes ou autres supports et sur colonnes montantes d’immeubles en caniveaux ou enterrés avec protection mécanique.

Description

  1. Âme rigide en cuivre unitaire rétreinte de classe 1 pour S ≤ 4 mm² ; rigide de classe 2 pour S ≥ 6 mm²
  2. Isolation : PR / XLPE
  3. Gaine : PVC noir résistant aux UV et aux intempéries.

Points particuliers

  • Tension nominale Uo/U ≈ 0,6/1Kv
  • Tension d’essai ≈ 3500 V
  • Résistance à l’eau type AD7 / type AD8 est sur demande

Description

Référence Section câble (mm²) Diamètre extérieur approx (mm) Masse approx (Kg/Km) Intensité admissible en ampères (1) Chute de tension V/A/Km cosØ=0.8 Conditionnement standard T : Touret (m)
A l’air libre 30°C En terre 20°C
Monophasé
RVFVB1.5+ 2 x 1.5 7.0 100 26 37 25.0 T 1000
RVFVB2.5+ 1 x 2.5 7.5 130 36 48 15.0 T 1000
RVFVB4+ 1 x 4 8.5 180 49 63 9.6 T 1000
RVFVB6+ 1 x 6 14.0 360 63 80 6.3 T 1000
RVFVB10+ 1 x 10 16.0 480 86 104 3.8 T 1000
RVFVB16+ 1 x 16 18.0 680 115 136 2.4 T 1000
RVFVB25+ 1 x 25 22.0 980 149 173 1.6 T 1000
RVFVB35+ 1 x 35 24.0 1250 185 208 1.2 T 1000
Triphasé
RVFVC1.5+ 3G1.5 7.5 120 23 31 21.0 T 1000
RVFVC2.5+ 3G25 8.0 160 31 41 13.0 T 1000
RVFVC4+ 3G4 9.5 230 42 53 8.3 T 1000
RVFVC6+ 3 x 6 15.0 450 54 66 5.5 T 1000
RVFVC10+ 3 x 10 17.0 600 75 87 3.3 T 1000
RVFVC16+ 3 x 16 19.0 820 100 113 2.1 T 500
RVFVC25+ 3 x 25 23.0  1200 127  144 1.3 T 1000
RVFVC35+ 3 x 35 25.0  1600  158  174 1.0 T 1000
RVFVC50+ 3 x 50 28.0  2000 192  206  0.77 T 1000
RVFVC70+ 3 x 70 33.0 2800 246 254  0.55 T 500
RVFVC95+ 3 x 95 38.0 4100 298 301  0.42 T 500
RVFVC120+ 3 x 120 42.0 5000 245 343  0.35 T 500
RVFVC150+ 3 x 150 46.0 6000 399 387  0.30 T 500
RVFVC185+ 3 x 185 51.0 7400 456 434  0.26 T 500
RVFVC240 3 x 240 57.0 9500 598 501  0.20 T 250
3 conducteurs cuivre ronds + Neutre                                                                Triphasé
RVFVC3516  3 x 35+16  26.0 1710  158  174  1.00 T 1000
RVFVC3525 3 x 35+25  27.0 1850  158 174 1.00 T 1000
RVFVC5025 3 x50+25 30.0 2250 192 206 0.77 T 1000
RVFVC5035+ 3 x 50+35 31.0 2400 192 206 0.77 T 1000
RVFVC7035+ 3 x 70+35 34.5 3200 246 254 0.55 T 1000
RVFVC7050+ 3 x 70+50 35.5 3300 246 254 0.55 T 1000
RVFVC9550+ 3 x 95+50 40.0 4550 298 301 0.43 T 500
RVFVC12070+ 3 x 120+70 45.0 5650 346 343 0.35 T 500
RVFVC15070+ 3 x 150+70 48.0 6700 399 387 0.30 T 500
RVFVC18570+ 3 x 185+70 52.0 8000 456 434 0.26 T 500
RVFVC18595+ 3 x 185+95 53.0 8250 456 434 0.26 T 500
RVFVC24095+ 3 x 240+95 59.0 10200 538 501 0.22 T 250
4 conducteurs + neutre cuivre rond                                                            Triphasé
RVFVD1.5+ 4G1.5 8.0 150 23 31 21.0 T 1000
RVFVD2.5+ 4G2.5 9.0 190 31 41 13.0 T 1000
RVFVD4+ 4G4 10.0 270 42 53 8.3 T 1000
RVFVD6+ 4 x 6 16.0 510 54 66 5.5 T 1000
RVFVD10+ 4 x 10 18.0 720 75 87 3.3 T 500
RVFVD16+ 4 x 16 21.0 1000 100 113 2.1 T 500
RVFVD25+ 4 x 25 25.0 1500 127 144 1.3 T 500
RVFVD35+ 4 x 35 28.0 2000 158 174 1.0 T 500
RVFVD50+ 4 x 50 31.0 2500 192 206 0.77 T 500
RVFVD70+ 4 x 70 38.0 3900 246 254 0.55 T 500
RVFVD95+ 4 x 95 42.0 5100 298 301 0.43 T 500
RVFVD120+ 4 x 120 47.0 6300 346 343 0.35 T 500
RVFVD150+ 4 x 150 51.0 7600 395 387 0.30 T 250
RVFVD185+ 4 x 185 56.5 9400 456 434 0.26 T 250
RVFVD240+ 4 x 240 63.0 12000 538 501 0.22 T 250
 5 conducteurs cuivre ronds                                                            Triphasé
RVFVE1.5+ 5G 1.5 9.0 170 23 31 21.0 T 1000
RVFVE2.5+ 5G 2.5 10.0 230 31 41 13.0 T 1000
RVFVE4+ 5G 4 11.0 320 42 53 8.3 T 1000
RVFVE6+ 5 x 6 18.0 620 54 66 5.5 T 1000
RVFVE10+ 5 x 10 20.0 900 75 87 3.3 T 1000
RVFVE16+ 5 x 16 22.0 1250 100 133 2.1 T 1000
RVFVE25+ 5 x 25 27.0 1850 127 144 1.2 T 1000
